Specifications:
part number:
description:
CA-2210
Cable, 1830 mm, 5.5x2.1x12 mm 50-00126
dc plug to 5.5x2.1 50-00025 dc jack, 18
AWG, 30-00007 wire
date: September 10, 2013
rev: A2
page: 1 of 2
connector description (1)
overmold (2,5)
connector description (6)
wire description (3)
cable outer diameter
cable color
cable length
twist tie (4)
rating
dc plug, 5.5x2.1xL22.5 mm, brass nickel plated, P/N 50-00126
30P, PVC, black
dc jack, 5.5x2.1xL17.4 mm, molding style, P/N 50-00025
2C, 18 AWG, UL2468, 300V, 80C, 4.4 mm, VW-1, PVC, 48P, P/N 30-00007
?4.4 mm
black
1830 +76/-25 mm
black
3 A, 36 Vdc
Notes:
Function test: no open, no reversed polarity, no short circuit, no INT
RoHS compliant
Hi-Pot test: 600 Vac, 0.5 mA, 1 second
Mechanical drawing:
Units: mm
tolerance
X: ±0.5 mm
.X: ±0.3 mm
.XX: ±0.05 mm
applicable unless otherwise indicated in specification or on drawings
Tensility International Corporation reserves the right to substitute
parts which are functionally equivalent to the ones specified.
Initial
Date
